Ethyl Carbitol

Ethyl Carbitol, also known by its chemical name 2-(2-Ethoxyethoxy)ethanol, belongs to a class of solvents known as glycol ethers. Glycol ethers are widely used for their exceptional solvency, low volatility, and miscibility with both water and organic compounds, making them useful in a variety of applications. Ethyl Carbitol was particularly significant in industries such as paints and coatings, cleaning agents, and textiles up to the year 2000.

Below is a detailed overview, focusing on its chemical properties, production methods, applications, health and safety aspects, environmental impact, and market trends up to the year 2000.

Table of Contents

1. Chemical Structure and Properties

Ethyl Carbitol (2-(2-Ethoxyethoxy)ethanol) is a diethylene glycol monoalkyl ether with the following chemical characteristics:

Molecular Formula: C6H14O3
Molecular Weight: 134.17 g/mol
Chemical Structure:
- The molecule consists of an ethoxy group (-CH₂CH₃) attached to a diethylene glycol chain (-CH₂CH₂OCH₂CH₂OH).
Boiling Point: 192°C (377.6°F)
Melting Point: -70°C (-94°F)
Density: 0.965 g/cm³ at 20°C
Vapor Pressure: 0.07 mmHg at 20°C
Solubility: Ethyl Carbitol is highly soluble in water and most organic solvents, including alcohols, ketones, and esters.

Physical Characteristics:

Appearance: Clear, colorless liquid.
Odor: Ethyl Carbitol has a mild, ether-like odor.
Viscosity: It is a relatively viscous liquid, which helps in applications requiring good flow and film-forming properties, such as coatings and paints.

2. Ethyl Carbitol Production Methods

The production involves the reaction between ethylene oxide and ethanol. This process is similar to that used in the synthesis of other glycol ethers and proceeds in the following steps:

Reaction of Ethylene Oxide with Ethanol: Ethylene oxide (C₂H₄O) reacts with ethanol (C₂H₅OH) to form ethoxyethanol (C₂H₅OCH₂CH₂OH). This is an intermediate product in the production of glycol ethers.
$C_{2} H_{4} O + C_{2} H_{5} OH \to C_{2} H_{5} OCH_{2} CH_{2} OH$
Subsequent Reaction with Ethylene Oxide: The intermediate ethoxyethanol then reacts with another molecule of ethylene oxide, forming the final product: Ethyl Carbitol (2-(2-Ethoxyethoxy)ethanol).
$C_{2} H_{5} OCH_{2} CH_{2} OH + C_{2} H_{4} O \to C_{2} H_{5} OCH_{2} CH_{2} OCH_{2} CH_{2} OH$

This process takes place in the presence of a catalyst, typically an alkali metal hydroxide such as sodium hydroxide (NaOH), and requires controlled temperatures to manage the highly reactive nature of ethylene oxide.

3. Applications

By 2000, Ethyl Carbitol had become a versatile solvent due to its balance of properties, such as low volatility, high boiling point, and good miscibility with water and organic solvents. Its applications were widespread across multiple industries:

3.1. Paints, Coatings, and Varnishes

one of the key solvents used in water-based paints and coatings. Its role in these formulations includes:

Film formation: It acts as a coalescing agent, promoting the proper formation of polymer films in latex paints and coatings.
Improved flow: It improves the application properties of paints and coatings, providing smooth flow and reducing the formation of defects like orange peel or streaks.
Low evaporation rate: Its relatively high boiling point ensures slow evaporation, which is important in producing a smooth, even finish and preventing premature drying during application.

It is also used in automotive paints and industrial coatings, where solvent resistance and durability are important.

3.2. Cleaning Products and Detergents

widely used as a solvent in cleaning formulations, particularly in products intended for industrial and household cleaning. It is a key ingredient in:

Degreasers: Used in removing oils, grease, and heavy soil from machinery and surfaces.
Glass and surface cleaners: Due to its ability to dissolve a range of substances while being mild on surfaces, it is commonly included in formulations for glass cleaners, all-purpose cleaners, and bathroom cleaners.
Paint strippers and graffiti removers: Its strong solvency helps to break down paints, varnishes, and other coatings, making it an effective ingredient in paint stripping products.

3.3. Textiles and Leather

Ethyl Carbitol is used in the textile industry for processes such as:

Dyeing: It improves the solubility of dyes in aqueous systems and helps with dye penetration into textile fibers.
Finishing agents: It is used in textile finishing formulations to impart softness and flexibility to fabrics.
Leather treatment: Ethyl Carbitol is used as a solvent for leather dyes and finishes, helping to ensure even coloration and smooth application of coatings.

3.4. Printing Inks

In the printing industry, Ethyl Carbitol is used in flexographic and gravure inks due to its ability to dissolve a variety of resins. It provides:

Ink stability: Ethyl Carbitol helps maintain the viscosity and flow of printing inks, ensuring uniform print quality.
Fast drying: Inks containing Ethyl Carbitol dry quickly, which is essential in high-speed printing processes, such as those used in packaging and newsprint.

3.5. Adhesives

serves as a solvent in the formulation of adhesives, particularly in products used for bonding plastics, rubber, and other materials. It helps dissolve polymer binders and improves the workability of adhesive formulations.

3.6. Cosmetics and Personal Care Products

Ethyl Carbitol is used in personal care formulations, such as:

Lotions and creams: It acts as a solvent for active ingredients in moisturizers and other skin care products.
Fragrances: It is used as a carrier for fragrances, ensuring the even distribution of scent compounds in products like perfumes and body sprays.

4. Health and Safety

While Ethyl Carbitol is less toxic than many other solvents, it is not entirely without health risks. Safety data and regulatory frameworks had already been well-established by the year 2000 to ensure its safe use in industrial and consumer products.

4.1. Toxicity

Acute toxicity: Ethyl Carbitol has low acute toxicity, but ingestion or inhalation of large amounts can cause nausea, headaches, and dizziness.
Chronic toxicity: Long-term exposure, particularly in industrial settings where vapor concentrations may be high, can potentially lead to liver and kidney damage. However, this is usually not a concern with normal use in consumer products.
Skin and eye irritation: Direct contact with Ethyl Carbitol may cause mild to moderate irritation of the skin and eyes, though it is not considered a strong irritant.

4.2. Occupational Exposure Limits

OSHA (Occupational Safety and Health Administration) set permissible exposure limits (PELs) to limit worker exposure to Ethyl Carbitol. For glycol ethers like Ethyl Carbitol, the PEL was set at 25 ppm (parts per million)over an 8-hour workday to protect workers from adverse health effects.

4.3. Fire and Explosion Hazards

Flammability: Ethyl Carbitol has a flash point of 85°C (185°F), which means it can ignite at elevated temperatures. Proper storage and handling procedures are necessary to prevent fire hazards in industrial settings.

5. Environmental Impact

Like many solvents, the environmental impact of Ethyl Carbitol depends on how it is used, disposed of, and regulated. By 2000, concerns over the environmental footprint of glycol ethers, including Ethyl Carbitol, were growing.

5.1. Biodegradability

Ethyl Carbitol is biodegradable, meaning it can be broken down by microorganisms in soil and water. This property helps mitigate its long-term environmental persistence compared to more hazardous solvents like chlorinated hydrocarbons.

5.2. Volatile Organic Compounds (VOCs)

Ethyl Carbitol is classified as a volatile organic compound (VOC), and its use in paints, coatings, and cleaning products contributes to VOC emissions. VOCs can lead to the formation of ground-level ozone and contribute to smog in urban areas. By 2000, regulations were being implemented in the United States and Europe to reduce VOC emissions, leading to changes in how solvents like Ethyl Carbitol were used, particularly in the paints and coatings industries.

5.3. Water Pollution

If released into waterways, Ethyl Carbitol can pose risks to aquatic life. Its high solubility in water means that it can readily disperse, but it is generally considered less toxic to aquatic organisms compared to more persistent or bioaccumulative substances.

6. Ethyl Carbitol Global Market and Economic Importance

By the year 2000, Ethyl Carbitol had established itself as an important industrial solvent, with production and consumption concentrated in regions with well-developed chemical industries, including North America, Europe, and Asia.

6.1. Market Demand

The demand for Ethyl Carbitol was closely tied to the growth of the paints, coatings, adhesives, and cleaning product industries. As environmental regulations on solvents increased, demand for more environmentally friendly glycol ethers like Ethyl Carbitol remained strong.
Asia: Growing industrialization in countries like China, India, and South Korea contributed to increasing demand for Ethyl Carbitol in the region.
North America and Europe: These regions accounted for significant consumption, especially in sectors like automotive coatings, printing inks, and specialty chemicals.

6.2. Trade

Ethyl Carbitol was traded globally, with major production hubs in the United States, Germany, France, and Japan. Multinational chemical companies like Dow Chemical, BASF, and Eastman Chemical were among the leading producers, supplying both local and international markets.

7. Future Prospects (As of 2000)

By the year 2000, the future prospects for Ethyl Carbitol were promising, with continued demand in paints, coatings, and cleaning products. However, increasing regulations on VOCs and environmental concerns were beginning to drive innovation toward more sustainable solvents. Research into bio-based glycol ethers and low-VOC formulations was gaining momentum, signaling potential changes in the market for Ethyl Carbitol and related compounds in the years to come.

PT. Samiraschem Indonesia is Reliable Supplier and Distributor Ethyl Carbitol with High Quality Product and Good Price. We are Serving and Delivered Area such Jakarta Bandung Semarang Jogja Surabaya Medan and Batam

Ethyl Carbitol (2-(2-Ethoxyethoxy)ethanol) had cemented its role as a versatile and widely used solvent by the year 2000. Its unique combination of properties—excellent solvency, low volatility, water miscibility, and relatively low toxicity—made it a valuable ingredient across various industries, including paints and coatings, cleaning agents, textiles, printing inks, and adhesives. However, environmental regulations and the push for safer, more sustainable chemicals were beginning to shape the landscape for solvents like Ethyl Carbitol, setting the stage for future innovations in solvent technology.
