Butyl Cellosolve

Butyl Cellosolve, also known as 2-butoxyethanol or ethylene glycol monobutyl ether, is a widely used glycol ether with the chemical formula $C_{6} H_{14} O_{2}$ . This organic compound combines properties of both alcohols and ethers, making it a versatile solvent for a variety of industrial and commercial applications. It is valued for its ability to dissolve both polar and nonpolar substances, making it essential in cleaning products, coatings, inks, and other formulations. Below, we’ll explore its structure, properties, production, applications, safety considerations, environmental impact, and its role in various industries in depth.

Table of Contents

1. Chemical Structure and Composition

Butyl Cellosolve is a member of the glycol ether family, which includes compounds with both an ether and an alcohol functional group.

Molecular Formula: $C_{6} H_{14} O_{2}$
Molecular Weight: 118.17 g/mol
IUPAC Name: 2-butoxyethanol
Common Names: Butyl Cellosolve, ethylene glycol monobutyl ether, butyl glycol, EGBE
Chemical Structure: $C H_{3} C H_{2} C H_{2} C H_{2} OC H_{2} C H_{2} O H$

The structure consists of a butyl group (a four-carbon chain) attached to an ethylene glycol group, which contains both ether (R-O-R) and alcohol (-OH) functional groups. This structure gives Butyl Cellosolve its unique solvent properties and enables it to interact with a wide range of other molecules.

2. Physical Properties of Butyl Cellosolve

physical properties make it highly effective in various applications, especially as a solvent in formulations that require both water and oil solubility.

Appearance: Clear, colorless liquid
Odor: Mild, sweet odor, similar to ether
Boiling Point: 171°C
Melting Point: -77°C
Density: 0.902 g/cm³ at 20°C
Solubility in Water: Miscible in water
Vapor Pressure: 0.8 mmHg at 20°C
Flash Point: 60°C (closed cup)

Butyl Cellosolve’s high boiling point and low vapor pressure contribute to its stability, while its miscibility with water and other organic solvents makes it ideal for applications where both water-based and oil-based materials need to be dissolved or mixed.

3. Production

The production typically involves an etherification reaction, where an ethylene glycol molecule reacts with an alcohol molecule. The two primary production methods are as follows:

a) Etherification Process

- produced by reacting ethylene oxide with butanol in the presence of an acid or base catalyst. The resulting product is 2-butoxyethanol, or Butyl Cellosolve: $C_{2} H_{4} O + C_{4} H_{9} OH \to C_{6} H_{14} O_{2}$
- This reaction is efficient and allows for large-scale production, making it the preferred method for manufacturing Butyl Cellosolve.

b) Byproduct of Other Processes

- Butyl Cellosolve can sometimes be a byproduct in the production of other glycol ethers. However, dedicated production methods like etherification are more commonly used for quality and purity control.

4. Chemical Properties of Butyl Cellosolve

chemical properties stem from its dual functional groups – the ether linkage and the hydroxyl (alcohol) group. These properties make it highly reactive in certain conditions and capable of participating in several chemical reactions.

Hydrogen Bonding: The hydroxyl group allows Butyl Cellosolve to form hydrogen bonds with other polar molecules, which contributes to its high solubility in water and certain organic compounds.
Solvent Capabilities: Its chemical structure enables it to dissolve both polar (water-based) and nonpolar (oil-based) substances, making it a unique solvent in applications that require compatibility with diverse substances.
Reactivity with Acids and Bases: Butyl Cellosolve can react with strong acids and bases, forming salts and esters that are useful in various chemical processes.
Combustion: Like most organic compounds, is flammable and can combust to produce carbon dioxide, water, and heat when exposed to open flame.

5. Applications

The unique solvent properties of Butyl Cellosolve make it indispensable in many industrial and consumer applications. Here are some of its primary uses:

a) Paints and Coatings

- extensively used in the paints and coatings industry due to its ability to dissolve a range of resins and pigments. It improves the flow and leveling properties of paints, leading to smoother and more uniform finishes.
- Its moderate evaporation rate allows for controlled drying times, making it suitable for both water- and solvent-based paints, varnishes, and coatings used in automotive, furniture, and architectural applications.

b) Cleaning Products

- In household and industrial cleaning products, acts as an effective grease and dirt remover. Its ability to dissolve both water-soluble and oil-based contaminants makes it an essential ingredient in glass cleaners, degreasers, and all-purpose cleaners.
- It is especially effective in breaking down greasy residues and is commonly used in formulations for kitchen and bathroom cleaners.

c) Printing Inks and Dyes

- used in printing inks and dyes as it helps to maintain uniform consistency, improve flow, and prevent clogging in printing equipment. It is compatible with a range of dyes and pigments, providing stability in the final product.
- In textile printing, it helps in even dye penetration and adherence, enhancing the durability of printed fabrics.

d) Adhesives and Sealants

- In the adhesives and sealants industry, used to dissolve resins and improve the adhesive properties of products. It is frequently used in pressure-sensitive adhesives, which are applied in tapes, labels, and other products requiring strong but removable adhesion.

e) Pharmaceuticals

- In pharmaceutical formulations, Butyl Cellosolve is occasionally used as a solvent or stabilizing agent. It can help dissolve certain active pharmaceutical ingredients, particularly those that require an amphiphilic solvent.

f) Agricultural Chemicals

- used as a solvent in some herbicides and pesticides, helping to evenly disperse active ingredients and improve the effectiveness of agricultural chemicals. It also acts as a carrier, aiding in the uniform application of these products across crops.

6. Safety and Handling of Butyl Cellosolve

While Butyl Cellosolve is a highly useful solvent, it is important to handle it with care due to its health and environmental risks.

a) Health Hazards

- Inhalation: Inhalation of Butyl Cellosolve vapors can irritate the respiratory tract and may lead to headaches, dizziness, and nausea. Prolonged exposure can affect the central nervous system.
- Skin Contact: Butyl Cellosolve can be absorbed through the skin, which can lead to irritation or dermatitis with prolonged exposure. In severe cases, it can cause skin burns.
- Eye Contact: Exposure to Butyl Cellosolve can cause severe eye irritation, potentially leading to redness, tearing, and blurred vision.
- Ingestion: Ingesting Butyl Cellosolve is dangerous and can cause gastrointestinal symptoms such as nausea, vomiting, and abdominal pain. Large amounts can have toxic effects on the liver and kidneys.

b) Occupational Exposure Limits (OELs)

- Many countries have set permissible exposure limits for Butyl Cellosolve. The Occupational Safety and Health Administration (OSHA) in the United States recommends a limit of 50 parts per million (ppm) for an eight-hour workday.

c) Fire and Explosion Hazards

- Butyl Cellosolve is flammable and can form explosive vapor-air mixtures. Its flash point is around 60°C, which means it should be kept away from open flames and sources of ignition.

d) Safety Precautions

- Personal Protective Equipment (PPE): It is advisable to use gloves, goggles, and respirators when handling Butyl Cellosolve.
- Ventilation: Adequate ventilation is necessary to prevent the accumulation of vapors.
- Storage: Store in a cool, well-ventilated area away from heat sources, direct sunlight, and oxidizing agents.

7. Environmental Impact of Butyl Cellosolve

Like many solvents, Butyl Cellosolve has environmental implications, especially when it comes to air and water pollution.

a) Air Pollution

- Butyl Cellosolve is a volatile organic compound (VOC) and contributes to air pollution. VOCs can form ground-level ozone, which is a major component of smog and can have detrimental effects on human health and the environment.

b) Water Contamination

- When released into water bodies, can be harmful to aquatic life, particularly if present in high concentrations. It can interfere with the reproductive and growth systems of fish and other aquatic organisms.

c) Biodegradability

- considered biodegradable, it can still have short-term effects on ecosystems if released improperly. Proper disposal and adherence to environmental regulations are essential to minimize its environmental footprint.

8. Regulatory Considerations

Due to its health and environmental risks, Butyl Cellosolve is regulated in many countries, both in terms of workplace exposure and environmental emissions.

OSHA Regulations: OSHA has set permissible exposure limits to protect workers from adverse health effects.
Environmental Protection Agency (EPA): In the U.S., the EPA regulates Butyl Cellosolve under the Clean Air Act, as it is considered a hazardous air pollutant.
Waste Disposal: Waste containing Butyl Cellosolve must be managed in accordance with hazardous waste guidelines to avoid environmental contamination.

PT. Samiraschem Indonesia is Reliable Supplier and Distributor Butyl Cellosolve with High Quality Product and Good Price. We are Serving and Delivered Area such Jakarta Bandung Semarang Jogja Surabaya Medan and Batam

Butyl Cellosolve, or 2-butoxyethanol, is a highly versatile solvent with a unique combination of properties that make it suitable for a wide range of industrial and commercial applications. Its ability to dissolve both polar and nonpolar substances makes it ideal for use in paints, coatings, cleaning products, inks, adhesives, and more. However, due to its potential health hazards and environmental impact, careful handling, storage, and disposal are necessary to ensure safety and sustainability.

Advances in green chemistry and the development of eco-friendly alternatives may help reduce the dependence on Butyl Cellosolve in the future, but for now, it remains an important solvent across industries. As regulations evolve and industries continue to focus on sustainability, managing the risks associated with Butyl Cellosolve will be essential to minimizing its environmental footprint while retaining its benefits as a versatile chemical.
